| Printing size | 600mm * 420mm |
| Motors | Servo motors |
| Print head | 2*EP DX10 |
| Media thickness | up to 200mm |
| Height adjustable | Automatic |
| Max. media weight | 30KG |
| Print method | Direct printing |
| Head printing precision | Overlap small than 0.1mm |
| Color | C.M.Y.K.LM.LC+W |
| Print resolution | 2880*1440dpi |
| Print interface | USB2.0/Ethernet |
| Print speed | Average 5~8m2/h |
| Print Direction | Bi/Uni direction |
| Operational environment | Temperature 20°C -40 °C; Humidity 30%-70% |
| Power | 50/60HZ, 220V(±10%) working 350W standby 30W |
| Ink volume | 500ml |
| Ink type | UV environmentally ink |
| Operational software | RIP software |
| UV lamp | LED UV lamps |
| UV power | 100W |
| UV lamp life time | 50000 hours |
| UV lamp system | 6 Power degree adjustable system |
| UV light wavelength | 390~400mm |
| Cooling type | Air cooling/ Water cooling |
| Cooling adjustment | Automatic on/off between 25~30°C |
| Ink drop size | Minimum 3.5pl ink,maximum28PI ink |
| Ink supply system | Continuous Ink Supply System(CISS) |
| Printer head protection | Intellective automatic detect |
| Printer head maintain | Head clean during/after printing, keep-wet system when idle. |
| Materials to print | Metal, plstic, glass, wood, ceramics, acrylic, leather,etc. |
| Software language | Korean, German, French, Portuguese, Japanese, Spanish, Italian,Finnish,Dutch, English, etc. |
| System requirement | Windows XP/Vista/Win 7/Linus |
| Net weight/ Gross weight | 85KG/135KG |
| Printer size | 750*1600*1160mm |
| Packing size | 950*1800*1310mm |
| Packing | Strong wooden package with full foam. |
| Warranty | Two years |
