1. Feature
Compact crawler travelstructure for placement, dismountable during construction for hydropower, highway and slope;
Full-hydraulic control, easy and flexible operation, time and labor saving, remote operation available.
Modular design to meet customer's requirements for different configuration.
Adoption of low-speed large-torque motor, thus achieving stable and reliable performance and long service life.
Wide applicable scope, strong drilling capacity; long stroke of power head, and high drilling efficiency.
Connection of power head and guide rail by wear-resistant plate, to achieve slight wearing of guide rail.
Large angle range for drilling; slidable rail back and forth along chassis frame, thus realizing easy and reliable positioning.
Applicable to multiple drilling methods.
2.Technical Parameters
Rated pressure of hydraulic system(Mpa) | 20 |
Borehole diameter(mm) | Φ100 – Φ150 |
Borehole depth(m) | 40 – 60 |
Crushing way | Rotary-perussion drill |
drill stem (mm) | Φ60×1500; Φ73×1500 |
Drilling angel(°) | 0-360 |
Maximum feeding force of power head (KN) | 20 |
Motor model(KW) | 11 |
Gross weight (kg) | About 260kg |
